Stable Baselines is a set of implementations of RL algorithms with a common interface, based on OpenAI Baselines. It focused on simplicity of use and consistency. In this article, we will present various examples (basic usage, saving/loading agents, easy multiprocessing, training on Atari games and more).

Getting Started

Associated Colab Notebook

With Stable Baselines, training a PPO agent is as simple as:

import gym

from stable_baselines.common.policies import MlpPolicy
from stable_baselines import PPO2

env = gym.make('CartPole-v1')

model = PPO2(MlpPolicy, env, verbose=1)
# Train the agent
model.learn(total_timesteps=10000)

# Enjoy trained agent
obs = env.reset()
for i in range(1000):
    action, _states = model.predict(obs, deterministic=False)
    obs, reward, done, info = env.step(action)
    env.render()
    if done:
        obs = env.reset()
env.close()

But with Stable Baselines, you can now define and train a RL agent in only one line of code:

from stable_baselines import PPO2

# Define and train a model in one line of code !
trained_model = PPO2('MlpPolicy', 'CartPole-v1').learn(total_timesteps=10000)
# you can then access the gym env using trained_model.get_env()

Basic Usage: Training, Saving, Loading

Associated Colab Notebook

In the following example, we will train, save and load an A2C model on the Lunar Lander environment.

import gym

from stable_baselines import A2C
from stable_baselines.common.policies import MlpPolicy
from stable_baselines.common.vec_env import DummyVecEnv

# Create and wrap the environment
env = gym.make('LunarLander-v2')
env = DummyVecEnv([lambda: env])

model = A2C(MlpPolicy, env, ent_coef=0.1, verbose=1)
# Train the agent
model.learn(total_timesteps=100000)
# Save the agent
model.save("a2c_lunar")
del model  # delete trained model to demonstrate loading

# Load the trained agent
model = A2C.load("a2c_lunar")

# Enjoy trained agent
obs = env.reset()
for i in range(1000):
    action, _states = model.predict(obs)
    obs, rewards, dones, info = env.step(action)
    env.render()

Multiprocessing: Unleashing the Power of Vectorized Environments

Associated Colab Notebook

import gym
import numpy as np

from stable_baselines.common.policies import MlpPolicy
from stable_baselines.common.vec_env import SubprocVecEnv
from stable_baselines.common import set_global_seeds
from stable_baselines import ACKTR

def make_env(env_id, rank, seed=0):
    """
    Utility function for multiprocessed env.

    :param env_id: (str) the environment ID
    :param rank: (int) index of the subprocess
    :param seed: (int) the inital seed for RNG
    """
    def _init():
        env = gym.make(env_id)
        env.seed(seed + rank)
        return env
    set_global_seeds(seed)
    return _init

env_id = "CartPole-v1"
num_cpu = 4  # Number of processes to use
# Create the vectorized environment
env = SubprocVecEnv([make_env(env_id, i) for i in range(num_cpu)])

model = ACKTR(MlpPolicy, env, verbose=1)
model.learn(total_timesteps=25000)

obs = env.reset()
for _ in range(1000):
    action, _states = model.predict(obs)
    obs, rewards, dones, info = env.step(action)
    env.render()

Monitoring Training with Tensorboard

OpenAI provided basic tensorboard support, we added full tensorboard integration (visualisation of the graph, learning curves and more).

To enable tensorboard logging, you just need to fill the tensorboard_log argument with a valid path:

tensorboard --logdir /tmp/a2c_cartpole_tensorboard/

from stable_baselines import A2C

model = A2C('MlpPolicy', 'CartPole-v1', verbose=1, tensorboard_log="/tmp/a2c_cartpole_tensorboard/")
model.learn(total_timesteps=50000)

Using Callback: Monitoring Training

Associated Colab Notebook

You can define a custom callback function that will be called inside the agent. This could be useful when you want to monitor training, for instance display live learning curves in Tensorboard (or in Visdom) or save the best agent.

import os

import gym
import numpy as np
import matplotlib.pyplot as plt

from stable_baselines.common.vec_env.dummy_vec_env import DummyVecEnv
from stable_baselines.bench import Monitor
from stable_baselines.results_plotter import load_results, ts2xy
from stable_baselines import DDPG
from stable_baselines.ddpg.noise import AdaptiveParamNoiseSpec


best_mean_reward, n_steps = -np.inf, 0

def callback(_locals, _globals):
    """
    Callback called at each step (for DQN an others) or after n steps (see ACER or PPO2)
    :param _locals: (dict)
    :param _globals: (dict)
    """
    global n_steps, best_mean_reward
    # Print stats every 1000 calls
    if (n_steps + 1) % 1000 == 0:
        # Evaluate policy performance
        x, y = ts2xy(load_results(log_dir), 'timesteps')
        if len(x) > 0:
            mean_reward = np.mean(y[-100:])
            print(x[-1], 'timesteps')
            print("Best mean reward: {:.2f} - Last mean reward per episode: {:.2f}".format(best_mean_reward, mean_reward))

            # New best model, you could save the agent here
            if mean_reward > best_mean_reward:
                best_mean_reward = mean_reward
                # Example for saving best model
                print("Saving new best model")
                _locals['self'].save(log_dir + 'best_model.pkl')
    n_steps += 1
    return True


# Create log dir
log_dir = "/tmp/gym/"
os.makedirs(log_dir, exist_ok=True)

# Create and wrap the environment
env = gym.make('LunarLanderContinuous-v2')
env = Monitor(env, log_dir, allow_early_resets=True)
env = DummyVecEnv([lambda: env])

# Add some param noise for exploration
param_noise = AdaptiveParamNoiseSpec(initial_stddev=0.2, desired_action_stddev=0.2)
model = DDPG('MlpPolicy', env, param_noise=param_noise, memory_limit=int(1e6), verbose=0)
# Train the agent
model.learn(total_timesteps=200000, callback=callback)

Atari Games

Associated Colab Notebook

Training a RL agent on Atari games is straightforward thanks to make_atari_env helper function. It will do all the preprocessing and multiprocessing for you.


from stable_baselines.common.cmd_util import make_atari_env
from stable_baselines.common.policies import CnnPolicy
from stable_baselines.common.vec_env import VecFrameStack
from stable_baselines import ACER

# There already exists an environment generator
# that will make and wrap atari environments correctly.
# Here we are also multiprocessing training (num_env=4 => 4 processes)
env = make_atari_env('PongNoFrameskip-v4', num_env=4, seed=0)
# Frame-stacking with 4 frames
env = VecFrameStack(env, n_stack=4)

model = ACER(CnnPolicy, env, verbose=1)
model.learn(total_timesteps=25000)

obs = env.reset()
while True:
    action, _states = model.predict(obs)
    obs, rewards, dones, info = env.step(action)
    env.render()

Mujoco: Normalizing input features

Normalizing input features may be essential to successful training of an RL agent (by default, images are scaled but not other types of input), for instance when training on Mujoco. For that, a wrapper exists and will compute a running average and standard deviation of input features (it can do the same for rewards).

import gym

from stable_baselines.common.policies import MlpPolicy
from stable_baselines.common.vec_env import DummyVecEnv, VecNormalize
from stable_baselines import PPO2

env = DummyVecEnv([lambda: gym.make("Reacher-v2")])
# Automatically normalize the input features
env = VecNormalize(env, norm_obs=True, norm_reward=False,
                   clip_obs=10.)

model = PPO2(MlpPolicy, env)
model.learn(total_timesteps=2000)

# Don't forget to save the running average when saving the agent
log_dir = "/tmp/"
model.save(log_dir + "ppo_reacher")
env.save_running_average(log_dir)

Retro Sonic

python3 -m retro.import /path/to/your/ROMs/directory/

import retro
from stable_baselines import PPO2
from stable_baselines.common.policies import CnnPolicy
from stable_baselines.common.vec_env import DummyVecEnv

env = retro.make(game='SonicAndKnuckles3-Genesis')
env = DummyVecEnv([lambda: env])

model = PPO2(policy=CnnPolicy, env=env, verbose=1)
model.learn(total_timesteps=10000)

obs = env.reset()
while True:
    action, _info = model.predict(obs)
    obs, rewards, dones, info = env.step(action)
    env.render()

Custom Policy Network

Stable baselines provides default policy networks for images (CNNPolicies) and other type of inputs (MlpPolicies). However, you can also easily define a custom architecture for the policy network:

from stable_baselines.common.policies import FeedForwardPolicy
from stable_baselines import A2C

# Custom MLP policy of three layers of size 128 each
class CustomPolicy(FeedForwardPolicy):
    def __init__(self, *args, **kwargs):
        super(CustomPolicy, self).__init__(*args, **kwargs,
                                           layers=[128, 128, 128],
                                           feature_extraction="mlp")

model = A2C(CustomPolicy, 'LunarLander-v2', verbose=1)
# Train the agent
model.learn(total_timesteps=100000)

Bonus: Continual Learning

You can also move from learning on one environment to another for continual learning (PPO2 on DemonAttack-v0, then transferred on SpaceInvaders-v0):

from stable_baselines.common.cmd_util import make_atari_env
from stable_baselines.common.policies import CnnPolicy
from stable_baselines import PPO2

# There already exists an environment generator
# that will make and wrap atari environments correctly
env = make_atari_env('DemonAttackNoFrameskip-v4', num_env=8, seed=0)

model = PPO2(CnnPolicy, env, verbose=1)
model.learn(total_timesteps=10000)

obs = env.reset()
for i in range(1000):
    action, _states = model.predict(obs)
    obs, rewards, dones, info = env.step(action)
    env.render()

# The number of environments must be identical when changing environments
env = make_atari_env('SpaceInvadersNoFrameskip-v4', num_env=8, seed=0)

# change env
model.set_env(env)
model.learn(total_timesteps=10000)

obs = env.reset()
while True:
    action, _states = model.predict(obs)
    obs, rewards, dones, info = env.step(action)
    env.render()
